Class to render a tiny space 4 bit per pixel font. More...

Inheritance diagram for Burger::Font4Bit:

[legend]

Collaboration diagram for Burger::Font4Bit:

[legend]

Classes
struct	RGBColorList_t

struct	State_t

Public Member Functions
const Burger::StaticRTTI *	get_StaticRTTI (void) const noexcept override
	Get the description to the class.

	Font4Bit (Renderer *pRenderer=0)
	Constructor.

virtual	~Font4Bit ()
	Destructor.

uint_t	GetPixelWidth (const char *pInput, uintptr_t uLength) override
	Determine the number of pixels the string will require to render onto the display.

void	DrawChar (uint_t uLetter) override
	Draw a single UTF32 character.

void	Init (RezFile pRezFile, uint_t uRezNum, const uint8_t pPalette, Renderer *pRenderer=0)
	Initialize a font structure.

void	Shutdown (void)
	Release a font back to the resource manager.

void	SaveState (State_t *pOutput)
	Save the current state of the font manager.

void	RestoreState (const State_t *pInput)
	Restore the previous state of the font manager.

void	SetColor (uint_t uColorIndex, uint_t uColor)
	Set a color for a font.

void	UseZero (void)
	Make color index #0 visible.

void	UseMask (void)
	Make color index #0 transparent.

void	InstallToPalette (RezFile pRezFile, uint_t uRezNum, const uint8_t pPalette)
	Install a font.

void	SetColorRGBListToPalette (const RGBColorList_t pRGBList, const uint8_t pPalette)
	Set the colors to a font.

void	SetToPalette (const uint8_t *pPalette)
	Set the font to use a different palette.

Public Member Functions inherited from Burger::Font
	Font (Display *pDisplay=0)
	Constructor.

virtual	~Font ()
	Destructor.

virtual void	Draw (const char *pInput, uintptr_t uLength)
	Draws a string of UTF8 text onto the screen.

void	SetDisplay (Display *pDisplay)
	Set the Display to use.

Display *	GetDisplay (void) const
	Get the Display currently in use.

void	SetX (int iX)
	Set the draw cursor X coordinate.

void	SetY (int iY)
	Set the draw cursor Y coordinate.

void	SetXY (int iX, int iY)
	Set the draw cursor X and Y coordinate.

int	GetX (void) const
	Get the draw cursor X coordinate.

int	GetY (void) const
	Get the draw cursor Y coordinate.

uint_t	GetHeight (void) const
	Get the height of the font in pixels.

uint_t	GetFirstChar (void) const
	Get the lowest valid character in UTF32 format that resides in the font.

uint_t	GetCount (void) const
	Get the highest valid character in UTF32 format that resides in the font.

uint_t	GetPixelWidthChar (uint_t uLetter)
	Given a UTF32 character code, return the width in pixels the typeface will render to.

uint_t	GetPixelWidthNumber (int32_t iInput)
	Determine the number of pixels needed to draw a numeric string.

uint_t	GetPixelWidthNumber (uint32_t uInput)
	Determine the number of pixels needed to draw a numeric string.

uint_t	GetPixelWidthString (const char *pInput)
	Determine the number of pixels needed to draw a UTF8 "C" string.

void	DrawNumber (int32_t iInput)
	Draw a signed numeric string.

void	DrawNumber (uint32_t uInput)
	Draw an unsigned numeric string.

void	DrawString (const char *pInput)
	Draw a UTF8 "C" string.

void	DrawStringCenterX (int iX, int iY, const char *pInput)
	Draw a centered string.

void	DrawStringAtXY (int iX, int iY, const char *pInput)
	Draw a string at a specific location.

uintptr_t	CharsForPixelWidth (const char *pInput, uint_t uWidth)
	Return the number of characters in a string that would fit in a pixel width.

Public Member Functions inherited from Burger::Base
const char *	get_class_name (void) const noexcept
	Get the name of the class.

virtual	~Base () noexcept=default
	Destructor.

Static Public Attributes
static const Burger::StaticRTTI	g_StaticRTTI

Static Public Attributes inherited from Burger::Font
static const Burger::StaticRTTI	g_StaticRTTI

Static Public Attributes inherited from Burger::Base
static const Burger::StaticRTTI	g_StaticRTTI
	The global description of the class.

Protected Attributes
union {

uint8_t Bytes [16]
	Color of font for 8 bit rendering. More...

uint16_t Shorts [16]
	Color of font for 16 bit rendering. More...

uint32_t Words [16]
	Color of font for 32 bit rendering. More...

}	m_ColorTable
	Storage for the color tables for rendering.

Renderer *	m_pRenderer
	Software renderer context.

RezFile *	m_pRezFile
	Resource file manager.

void **	m_ppData
	Handle to the active font.

uintptr_t	m_uPixelOffset
	Offset to the pixel array.

uint_t	m_uRezNum
	Resource ID of the last font loaded.

uint_t	m_uInvisibleColor
	Color to ignore for drawing.

Protected Attributes inherited from Burger::Font
Display *	m_pDisplay
	Rendering context to draw into.

int	m_iX
	X coord to draw the font.

int	m_iY
	Y coord to draw the font.

uint_t	m_uHeight
	Height of the font in pixels.

uint_t	m_uFirst
	First allowable UTF32 code that can be drawn.

uint_t	m_uCount
	Number of characters in the font.

Private Member Functions
	Font4Bit (const Font4Bit &)=delete

Font4Bit &	operator= (const Font4Bit &)=delete

	Font4Bit (Font4Bit &&)=delete

Font4Bit &	operator= (Font4Bit &&)=delete

Detailed Description

Class to render a tiny space 4 bit per pixel font.

For systems with tight memory requirements, this font renderer store the font strike at 4 bits per pixel to allow color rendering while occupying only a fraction of the space a full texture based font would take.

Use the font creation tool in MakeRez to create font data for this class

This font type is optimized for software rendering

Constructor & Destructor Documentation

◆ Font4Bit() [1/3]

Burger::Font4Bit::Font4Bit ( const Font4Bit & )

privatedelete

◆ Font4Bit() [2/3]

Burger::Font4Bit::Font4Bit ( Font4Bit && )

privatedelete

◆ Font4Bit() [3/3]

Burger::Font4Bit::Font4Bit ( Renderer * pRenderer = 0 )

Constructor.

Initializes all shared variables to defaults.

Parameters

pRenderer Pointer to a rendering context to use for low level APIs

◆ ~Font4Bit()

Burger::Font4Bit::~Font4Bit ( )

virtual

Destructor.

Release all resources allocated by the font manager

See also: Shutdown()

Member Function Documentation

◆ DrawChar()

void Burger::Font4Bit::DrawChar ( uint_t uLetter )

overridevirtual

Draw a single UTF32 character.

Given a valid UTF32 code, draw the single character

Parameters

uLetter UTF32 character code to draw

See also: Draw(const char *,uintptr_t)

Reimplemented from Burger::Font.

◆ get_StaticRTTI()

const Burger::StaticRTTI * Burger::Font4Bit::get_StaticRTTI ( void ) const

overridevirtualnoexcept

Get the description to the class.

This virtual function will pull the pointer to the StaticRTTI instance that has the name of the class. Due to it being virtual, it will be the name of the most derived class.

Returns: Pointer to a global, read only instance of StaticRTTI for the true class

Reimplemented from Burger::Font.

◆ GetPixelWidth()

uint_t Burger::Font4Bit::GetPixelWidth	(	const char *	pInput,
		uintptr_t	uLength )

overridevirtual

Determine the number of pixels the string will require to render onto the display.

Given a string of UTF8 text, determine the number of pixels will be needed to render the string. Return the value. Clipping is not considered in the calculation. Any invalid UTF8 characters or characters that are not present in the font are skipped.

Parameters

pInput	Pointer to a UTF8 string. If NULL or an empty string, return zero
uLength	Length of the string in bytes

See also: Draw(const char *,uintptr_t)

Reimplemented from Burger::Font.

◆ Init()

void BURGER_API Burger::Font4Bit::Init	(	RezFile *	pRezFile,
		uint_t	uRezNum,
		const uint8_t *	pPalette,
		Renderer *	pRenderer = 0 )

Initialize a font structure.

Load a font from a resource file and prepare it for drawing. This will set the font to consider color #0 to be invisible

Parameters

pRezFile	Pointer to the resource file that the font resides in
uRezNum	Resource number of the font file
pPalette	Palette to use for drawing
pRenderer	Rendering context to use for drawing

See also: InstallToPalette()

◆ InstallToPalette()

void BURGER_API Burger::Font4Bit::InstallToPalette	(	Burger::RezFile *	pRezFile,
		uint_t	uRezNum,
		const uint8_t *	pPalette )

Install a font.

Load a font from the resource file and use the currently attached Display to determine how to render the image

Parameters

pRezFile	Pointer to the resource file that the font resides in
uRezNum	Resource number of the font file
pPalette	Palette to use for drawing

◆ operator=() [1/2]

Font4Bit & Burger::Font4Bit::operator= ( const Font4Bit & )

privatedelete

◆ operator=() [2/2]

Font4Bit & Burger::Font4Bit::operator= ( Font4Bit && )

privatedelete

◆ RestoreState()

void BURGER_API Burger::Font4Bit::RestoreState ( const State_t * pInput )

Restore the previous state of the font manager.

Parameters

pInput Pointer to a initialized structure that contains a previous state.

See also: SaveState()

◆ SaveState()

void BURGER_API Burger::Font4Bit::SaveState ( State_t * pOutput )

Save the current state of the font manager.

Capture the current state of font manager so it can be restored later Values include the location of the draw cursor and the color rendering modes

Parameters

pOutput Pointer to a uninitialized structure to contain the state.

See also: RestoreState()

◆ SetColor()

void BURGER_API Burger::Font4Bit::SetColor	(	uint_t	uColorIndex,
		uint_t	uColor )

Set a color for a font.

Parameters

uColorIndex	Index into the color table, maximum value is 15
uColor	Color in the current color mode to draw with

◆ SetColorRGBListToPalette()

void BURGER_API Burger::Font4Bit::SetColorRGBListToPalette	(	const RGBColorList_t *	pRGBList,
		const uint8_t *	pPalette )

Set the colors to a font.

Using a RGB color list, set all the colors to a mounted font.

Note: The palette provided must be the colors needed for rendering

◆ SetToPalette()

void BURGER_API Burger::Font4Bit::SetToPalette ( const uint8_t * pPalette )

Set the font to use a different palette.

When a palette is changed, call this function to alert the font manager of the new color scheme. Needed when rendering to 15 bit or higher bit depths since palette changes are manually performed

Parameters

pPalette Pointer to a 256 color RGB palette

◆ Shutdown()

void BURGER_API Burger::Font4Bit::Shutdown ( void )

Release a font back to the resource manager.

Release all resource allocated by the font

◆ UseMask()

void Burger::Font4Bit::UseMask ( void )

inline

Make color index #0 transparent.

◆ UseZero()

void Burger::Font4Bit::UseZero ( void )

inline

Make color index #0 visible.

Member Data Documentation

◆ Bytes

uint8_t Burger::Font4Bit::Bytes[16]

Color of font for 8 bit rendering.

◆ g_StaticRTTI

const Burger::StaticRTTI Burger::Font4Bit::g_StaticRTTI

static

◆ [union]

union { ... } Burger::Font4Bit::m_ColorTable

Storage for the color tables for rendering.

◆ m_ppData

void** Burger::Font4Bit::m_ppData

protected

Handle to the active font.

◆ m_pRenderer

Renderer* Burger::Font4Bit::m_pRenderer

protected

Software renderer context.

◆ m_pRezFile

RezFile* Burger::Font4Bit::m_pRezFile

protected

Resource file manager.

◆ m_uInvisibleColor

uint_t Burger::Font4Bit::m_uInvisibleColor

protected

Color to ignore for drawing.

◆ m_uPixelOffset

uintptr_t Burger::Font4Bit::m_uPixelOffset

protected

Offset to the pixel array.

◆ m_uRezNum

uint_t Burger::Font4Bit::m_uRezNum

protected

Resource ID of the last font loaded.

◆ Shorts

uint16_t Burger::Font4Bit::Shorts[16]

Color of font for 16 bit rendering.

◆ Words

uint32_t Burger::Font4Bit::Words[16]

Color of font for 32 bit rendering.

Classes

Public Member Functions

Static Public Attributes

Protected Attributes

Private Member Functions

Detailed Description

Constructor & Destructor Documentation

◆ Font4Bit() [1/3]

◆ Font4Bit() [2/3]

◆ Font4Bit() [3/3]

◆ ~Font4Bit()

Member Function Documentation

◆ DrawChar()

◆ get_StaticRTTI()

◆ GetPixelWidth()

◆ Init()

◆ InstallToPalette()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ RestoreState()

◆ SaveState()

◆ SetColor()

◆ SetColorRGBListToPalette()

◆ SetToPalette()

◆ Shutdown()

◆ UseMask()

◆ UseZero()

Member Data Documentation

◆ Bytes

◆ g_StaticRTTI

◆ [union]

◆ m_ppData

◆ m_pRenderer

◆ m_pRezFile

◆ m_uInvisibleColor

◆ m_uPixelOffset

◆ m_uRezNum

◆ Shorts

◆ Words
